PICTURES OF MY SPORTSTER

Misc pictures of my bike. The first ones were taken on the first day when I picked up the bike (2nd April 2005)

Videos showing me on the bike driving away. The first one (on the left) shows the bike with stock pipes (about 1.7 MB) and the second one with Screamin Eagle pipes (about 1.6 MB).

These are pictures from a drive in Hunnedalen outside Stavanger in the beginning of September 2005

Information about the Sportster 883 Custom (information is taken from Harley-Davidson.com)

DIMENSIONS	METRIC UNITS
Length	2293.6 mm
Seat Height
Laden	673 mm
Unladen	718.8 mm
Ground Clearance	111.8 mm
Rake Steering Head/Trail	30.1º / 119.4 mm
Wheelbase	1534.2 mm
Fuel Capacity	17.0 L
Oil Capacity	3.4 L
Weight
Dry Weight	253.0 kg
Running Order	263.0 kg
POWERTRAIN
Engine	Evolution®
Displacement	883 cm³
Bore x Stroke	76.20 mm x 96.82 mm
Engine Torque	69.0 nm @ 4300 rpm
Fuel System	Carburetor
Compression Ratio	8.9:1
Liters per 100 KM
Carb.	4.1 hwy / 4.9 city
ESPFI	N/A
Primary Drive	Chain
Gear Ratio (overall)
1st	10.944
2nd	7.524
3rd	5.834
4th	4.806
5th	4.071
WHEELS/TIRES
Wheels
Front	Steel laced
Rear	Silver cast aluminum solid disc
Tire Size
Front	MH90-21 54H
Rear	150/80B16 71H
ELECTRICAL
Electronics	Optional security system
Instruments	Electronic speedometer; odometer; resettable tripmeter; diagnostic readout
Indicator Lamps	Oil pressure; engine diagnostics
CHASSIS
Brakes (diameter x width)
Front	292.1 mm x 5.08 mm
Rear	292.1 mm x 5.84 mm
Lean Angle (per SAEJ1168)	31º / 29º
Exhaust System	Staggered shorty duals
